Precision Stainless Steel Taper Pins
Use Omnicomponents' Part Numbers or Reference Any Manufacturers' Part Number In Your Request For Quote |
|
Allied Devices / PIC Design / WM Berg / Omnicomponents Corp.
Part Number Cross-Reference
Alternate materials or dimensions available upon request
Part Number Cross-Reference
Alternate materials or dimensions available upon request
|
|
Allied Devices
DC29 DC211 DC210 DC21 DC22 DC26 DC23 DC24 DC27 DC28 DC213 DC214 DC217 DC218 DC219 DC220 DC25 DC221 DC222 DC223 DC224 DC225 DC226 DC227 DC228 DC229 DC230 DC231 DC232 DC233 DC234 DC235 |
WM Berg
CP3-20 CP3-22 CP3-21 CP3-1 CP3-2 CP3-24 CP3-3 CP3-4 CP3-25 CP3-26 CP3-27 CP3-5 CP3-6 CP3-28 CP3-29 CP3-7 CP3-8 CP3-32 CP3-33 CP3-34 CP3-35 CP3-36 CP3-37 CP3-9 CP3-10 CP3-38 CP3-39 CP3-11 CP3-40 CP3-12 CP3-41 |
Omnicomponents
TP031X250 TP031X375 TP047X250 TP047X375 TP047X500 TP0625X375 TP0625X4375 TP0625X500 TP0625X5625 TP0625X625 TP078X4375 TP078X500 TP078X5625 TP078X625 TP078X750 TP094X500 TP094X5625 TP094X625 TP094X750 TP094X875 TP109X625 TP109X750 TP109X875 TP109X1000 TP125X625 TP125X750 TP125X875 TP125X1000 TP141X750 TP141X875 TP141X1000 TP141X1250 |
Pin
#9/0 #9/0 #8/0 #8/0 #8/0 #7/0 #7/0 #7/0 #7/0 #7/0 #6/0 #6/0 #6/0 #6/0 #6/0 #5/0 #5/0 #5/0 #5/0 #5/0 #4/0 #4/0 #4/0 #4/0 #3/0 #3/0 #3/0 #3/0 #2/0 #2/0 #2/0 #2/0 |
Diameter
.031 .031 .047 .047 .047 .0625 .0625 .0625 .0625 .0625 .078 .078 .078 .078 .078 .094 .094 .094 .094 .094 .109 .109 .109 .109 .125 .125 .125 .125 .141 .141 .141 .141 |
Length
1/4 3/8 1/4 3/8 1/2 3/8 7/16 1/2 9/16 5/8 7/16 1/2 9/16 5/8 3/4 1/2 9/16 5/8 3/4 7/8 5/8 3/4 7/8 1 5/8 3/4 7/8 1 3/4 7/8 1 1¼ |
